2 Hangar 9 Sukhoi SU-26MM SE
WARNING: Read the ENTIRE instruction manual to
become familiar with the features of the product before
operating. Failure to operate the product correctly can result
in damage to the product, personal property and cause
serious injury.
This is a sophisticated hobby product and NOT a toy. It must
be operated with caution and common sense and requires
some basic mechanical ability. Failure to operate this Product
in a safe and responsible manner could result in injury or
damage to the product or other property. This product is not
intended for use by children without direct adult supervision.
Do not attempt disassembly, use with incompatible
components or augment product in any way without the
approval of Horizon Hobby, Inc. This manual contains
instructions for safety, operation and maintenance. It is
essential to read and follow all the instructions and warnings
in the manual, prior to assembly, setup or use, in order to
operate correctly and avoid damage or serious injury.
Introduction
Congratulations on the purchase of your new Hangar 9
Sukhoi SU-26MM SE. As of right now, all that stands
between you and your first flight with it is about a day’s
worth of final assembly. We’ve already installed five
Spektrum A6030 digital high-torque servos and their
linkages on the control surfaces. We’ve even installed a
Spektrum A6000 throttle servo and the fuel tank for you. All
you have to do is attach the tail, slide on the wings, install
the engine and receiver, and put on the cowl.
Because the Sukhoi SU-26MM SE was designed by
aerobatic champ Mike McConville, you can look forward
to competition-level 3D performance. Its low wing loading
and lightweight construction will let you fly extreme 3D
maneuvers with power to spare using any of the most
popular 80cc to 85cc gas engines. It’s an excellent precision
aerobatic plane, too.
We sincerely hope you have as much fun with the Sukhoi
SU-26MM SE as we did testing it. If you get a chance, let
us know how your experience was by visiting Hangar-9.com
and clicking on the “Contact Us” section. We look forward to
hearing from you.
Happy flying,
The Hangar 9 Team
Product Support
For technical assistance with this product, please contact the
appropriate Horizon Product Support office. See warranty for
more information.
Specications
Wingspan 97.0 in (2.5m)
Length 91.0 in (2.3m)
Wing Area 1760 sq in (114 sq dm)
Weight 21.5–24.0 lb (9.80–11.0 kg)
Radio 4-channel (or greater)
Engine 80cc–85cc Gas
Servos Spektrum A6030 Digital
High-Torque (5)
Spektrum A6000 Digital Sport
Servo (Throttle)
Notice
All instructions, warranties and other collateral
documents are subject to change at the sole discretion
of Horizon Hobby, Inc. For up-to-date product
literature, visit http://www.horizonhobby.com and click
on the support tab for this product.
Meaning of Special Language
The following terms are used throughout the product
literature to indicate various levels of potential harm
when operating this product:
NOTICE: Procedures, which if not properly followed,
create a possibility of physical property damage AND a
little or no possibility of injury.
CAUTION: Procedures, which if not properly followed,
create the probability of physical property damage AND
a possibility of serious injury.
WARNING: Procedures, which if not properly
followed, create the probability of property damage,
collateral damage, and serious injury OR create a high
probability of superficial injury.
Table of Contents
Notice ................................................................................2
Meaning of Special Language ...........................................2
Introduction ......................................................................2
Product Support ...............................................................2
Specifications ....................................................................2
Included Parts Listing .......................................................3
Contents of Kit and Parts Listing ......................................4
Safety Precautions and Warnings .....................................4
Important Information Regarding Warranty ......................5
Using the Manual ..............................................................5
UltraCote® Covering Colors .............................................5
Recommended Evolution Engine ......................................5
DA 85 Engine ....................................................................5
Transmitter Requirements.................................................5
Radio Equipment Requirements .......................................5
Optional Choke Servo .......................................................5
Required Tools ..................................................................5
Required Adhesives ..........................................................6
Field Equipment Required .................................................6
Optional Field Equipment ..................................................6
Before Starting Assembly .................................................6
Receiver Installation ..........................................................6
Battery and Regulator Installation - 3D Flight ...................8
Battery and Regulator Installation -
Precision Aerobatics ..................................................9
Engine Installation (Evolution 80GX) ..............................11
Optional Tuned Pipe Installation .....................................16
Engine Installation (DA85) ..............................................18
Rudder and Tail Wheel Installation .................................20
Stabilizer Installation .......................................................21
Landing Gear Installation ................................................22
Wing Installation .............................................................23
Decal Placement .............................................................24
Center of Gravity .............................................................25
Checking the Control Linkages and
Centering the Control Surfaces ................................25
Control Throws ...............................................................26
Preflight ..........................................................................26
Range Test Your Radio ...................................................27
Safety Do’s and Don’ts for Pilots ....................................27
Daily Flight Checks ..........................................................27
Warranty and Repair Policy ............................................28
Warranty Services ...........................................................28
Compliance Information for the European Union ............29
2010 Official Academy of
Model Aeronautics Safety Code ...............................29
